GSI COLORIZE

The GSI COLORIZE printer is a remarkable new high-resolution printer that directly produces stunning color images on most porous and non-porous substrates. With the capability of inline or near line operation, the GSI COLORIZE printer allows users to integrate functional coding and product labeling with ultra high-quality logos and full color media, in real time, without the need to use pre-printed labels.

PRODUCT FEATURES

Available configurations for printing on light or dark surfaces
Direct to package print with UV cured inks
Permanent image means no labels falling off
Faster production speeds vs. print & apply
Unlimited unique label configurations in real time
High contrast bar codes for exceptional scanning results
Create vivid graphics for your package on demand
Up to 1” throw distance for maximum flexibility
Connect to any ERP via table data

CONFIGURATION OPTIONS

CMYK for Light Substrate

CMYK+W for Dark or Light Substrates

PRINT SAMPLES

High Resolution Comparison Features

PERFORMANCE

Resolution

180 V-DPI x 3600 H-DPI

Printing Speed

1,000 f/pm (304 m/min)

Colours per Head

Printing Height

4.25"-(Single Head) 8.5"-( Dual Head Stitched)

Message Length

Unlimited

Printable Substrates

Porous or Non-Porous

Printing Distance

Up to 1" (25mm)

Orientation

Side and Top

Barcodes

Code 128, UPC, ITF, Data Matrix, Maxicode, PDF-417 and more

USER INTERFACE

Controller

Touch Screen, PC, Tablet, Smart Phone

Message Editor

GSI Colorize IT Embedded, External XML, JSON, ZPL

Variable Data Fields

Unlimited

Image Formats

PNG, JPG, TIFF

GENERAL FEATURES

Display Features

N/A

Ink Range

Cyan, Magenta, Yellow, Black (Plus White in CMYK+W version)

CONNECTIONS/INTERFACING

Input/Output

2 Encoder Inputs, 1 Trigger Input, 4 Configurable Inputs, 6 Configurable Outputs, 1 Relay Circuit, Ethernet TCP/IP

RS232

N/A

Ethernet

Yes

USB

N/A

ELECTRONICS

Power Supply

12--240 VAC 50-60 Hz

ENVIRONMENT

Temperature

40F - 110F (5C - 40C)

Humidity

90% Relative Humidity, Non-Condensing
